KPC FIELD TOOL

ANTENNA CALCULATOR

Starting wire lengths for portable dipoles, linked dipoles, end-fed half-waves and quarter-wave verticals, whip settings for 17-ft and 25-ft telescoping verticals, plus how much signal your coax eats before it reaches the antenna.

πŸ“ Dipoles & EFHWπŸ“‘ Verticals & whipsπŸ”Œ Coax loss
Portable ham station with a tripod mast antenna on a ridge above a Kentucky lake at sunset

More calculators: delta & full-wave loops Β· doublet & ladder-line feeder Β· J-pole, Slim Jim & yagi Β· transformer builds Β· loading coil (short verticals) Β· harmonics & multiband wire

Linked dipole planner

Tap the bands your linked dipole should cover (it uses the wire adjustment above). Highest band is built and tuned first.

Measure each leg from the center insulator to the middle of the link, and add a few inches at every link and end for connector loops and trimming. Set both legs alike. Start long and trim while watching SWR.

Coax loss

Matched-line loss from typical published figures (approximate). High SWR on the coax adds more loss.

Random wire (9:1 unun)

Non-resonant end-fed wires used with a 9:1 unun and a tuner. These commonly published lengths avoid a half-wave on the popular bands β€” good starting points, not guarantees:

Run a counterpoise (17–25 ft is common) and use a tuner. Your height, ground and layout change what works best.

Ladder-line doublets & G5RV

Center-fed wires that cover many bands with a tuner. Ladder line keeps the loss low even at high SWR.

ANTENNAWIREFEEDLINEBANDS
88 ft doublet2 Γ— 44 ftLadder line to a tuner80–10 m
44 ft doublet2 Γ— 22 ftLadder line to a tuner40–10 m (80 m with a good tuner)
135 ft doublet2 Γ— 67.5 ftLadder line to a tuner160–10 m
G5RV102 ft~30.5 ft of 450 Ξ© window line, then coax20 m without a tuner; others with one
G5RV Jr51 ft~15.3 ft of window line, then coax40–10 m with a tuner
ZS6BKW93.5 ft~40–42 ft of 450 Ξ© window line, then coax40/20/17/12/10 m often under 2:1

Check your feeder length for every band β†’

Read: Ladder line, doublets & the G5RV β†’

VHF / UHF: J-pole, Slim Jim & ground plane

Copper or aluminum (velocity factor 0.96). Feed points are starting spots: slide them for the lowest SWR. Cut long and trim.

Full VHF/UHF calculator: Slim Jim from ladder line, roll-up J-pole, yagi β†’

Loops

Full-wave loop and delta side are in the cards at the top and the table below. A delta needs a ΒΌ-wave 75 Ξ© matching section or a 2:1.

Loop calculator: delta on your pole, matching section β†’

Magnetic loop calculator β†’

Receive-only antennas

A Loop on Ground is about 15 ft per side (60 ft of wire) on the grass, fed with a 3:9 turn transformer. It hears through low-band noise.

Build a Loop on Ground β†’

Transformers & chokes β†’

QUICK REFERENCE

All Bands At A Glance

BANDFREQDIPOLE TOTALEACH DIPOLE LEGEFHW WIREΒΌ-WAVE VERTICALFULL-WAVE LOOP
Lengths use the classic formulas β€” half-wave 468 Γ· MHz feet, quarter-wave 234 Γ· MHz feet β€” which already allow for typical wire end effects. Real antennas vary with wire, insulation, height and nearby objects, so cut a little long and trim while checking SWR. End-fed half-waves usually need a 49:1 (or 64:1) transformer. Transmit only within your license privileges.
KPC tools and guides are planning aids, not official sources. We make mistakes. Do your own research and check official maps. KPC is an independent ham radio club, not part of Parks on the Air®, SOTA or WWFF.
